Specialized Turbo Vado 5.0 Step-Through Electric Bike 2023

TURBO Vado 5.0 Step-Through Electric Bike 2023 is your ticket to fast, reliable, and confident transport.

Capable of covering long distances and loaded with useful features, Vado is a class leader in e-mobility. harness Turbo technology for 4x the power of your own pedals, accompanied by a full-function, bike computer. Comfort is guaranteed thanks to an 80mm suspension fork, larger tires, and a plush suspension seat post. And with anti-theft measures such as an in-built lock and alarm, you can trust the Vado to take you from 'A to B'. Get ready to put the pedal to the metal!

Features:

Turbo Full Power 2.2 motor and 710Wh battery offer an unparalleled riding experience, providing a smooth, seamless, and shockingly quiet amplification of your efforts, up to 28 mph. The integrated controller responds to your pedal inputs resulting in intuitive amplification of your efforts with an incredibly natural feel.

MasterMind and Specialized app - The MasterMind display reveals all relevant info about your ride and allows real-time tuning of support levels. MasterMind seamlessly integrates with the Specialized app for range optimization tools, advanced tuning, on-ride diagnostics, and more.

Proven Smooth Efficiency - We designed a custom testing mechanism to analyze bumps at even the smallest frequency to increase comfort and vision. That precision, paired with a suspended seatpost, higher volume tires, and an 80 mm suspension fork, will flatten roads before your eyes.

Turbo System Lock - Use the Specialized app to disable your bike's motor and activate the motion sensor alarm. Once locked, the motor cannot be enabled again except by the owner.

Garmin Radar - An integrated Garmin Radar sensor lets you know when traffic is coming up behind you. Garmin's Radar technology can detect cars up to 140 meters away. MasterMind will give riders a visual, audible, and haptic alert of an approaching vehicle's relative distance and rate of speed.

Fully Integrated Removable and Lockable Downtube Battery - Easy to charge, easy to secure.

Equipped with DRYTECH Fenders, LED front and rear lights, and 27kg capacity rear HD Rack. The rear rack is compatible with child bike seats, and the bike is also rated to pull a thru-axle trailer.

Long-Range - With a ride-anywhere range, go up to 75 miles (120 km) or 5.5 hours on a single charge (eco mode).

Specifications

E-Bike Specifications

Charger & Electronics

• Charger: Custom charger, 42V4A w/ Rosenberger plug, 100-240V
• UI/Remote: MasterMind TCD, w/ handlebar remote, built-in anti-theft feature, Bluetooth connectivity, customizable display pages
• Motor: Specialized 2.2, 90Nm torque, custom-tuned motor, 250W nominal
• Battery: Specialized U2-710, alloy casing, state of charge display, 710Wh

Frameset

• Frame: E5 Aluminum, bottom bracket motor mount, fully integrated & lockable downtube battery, internal cable routing, lock and front rack mount
• Seat Binder: Specialized Alloy 34.9, Steel Bolt

Suspension

• Fork: RockShox Recon Silver RL, 80mm travel, Motion-Control, fender mounts

Brakes

• Front Brake: SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm
• Rear Brake: SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm

Drivetrain

• Chainrings: Praxis, 48T, 104BCD
• Crankset: Custom alloy forged crankarms
• Chaincase: Custom chaincover
• Chain: KMC e11T, 11-speed w/ Missing Link
• Rear Derailleur: SRAM GX, long cage, 11-speed
• Cassette: SRAM PG-1130, 11-speed, 11-42t
• Shift Levers: SRAM S700, single-click lever

Wheels & Tires

• Rims: 650b disc, double-wall alloy, pinned, 32h
• Rear Hub: Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
• Front Hub: Specialized alloy front hub disc, sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 32h
• Spokes: DT Swiss Industry
• Front Tire: Pathfinder Sport Reflect, 650Bx2.3
• Rear Tire: Pathfinder Sport Reflect, 650Bx2.3
• Inner Tubes: Standard 40mm SV 650Bx1.75-2.4

Cockpit

• Saddle: Bridge Sport, Steel rails, 155mm
• Grips: Ergon GA30
• Stem: Specialized Flowset, 3D-forged alloy, 20-degree rise, 31.8mm clamp
• Handlebars: Specialized, alloy, 15-degree backsweep, 46mm rise, 31.8mm
• SeatPost: Spring suspension, alloy, 40mm travel, 30.9mm, 2-bolt clamp, 34.9mm sleeve

Accessories

• Fenders: Specialized DRYTECH fenders, 65mm width, aluminum fenderstay
• Radar: Integrated Garmin Radar, with custom information displayed directly on the Mastermind TCD
• Headlight: Lezyne Ebike Power E115, 310 Lumen, 12V
• Taillight: Spanninga Commuter Glow XE, 12V
• Pedals: Specialized Commuter w/ grip tape & reflectors
• Bell: Specialized brass bell
• Kickstand: Specialized kickstand, 40mm mount
• Rack: Specialized rack, MIK HD interface, built-in pannier mounts, 27kg max load
• Bike Lock: Turbo System Lock

Product Details

• Compliance Certification: As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS. For information on lithium-ion battery standards and regulations in New York City, visit: www.nyc.gov/fdny/batteries
• Product ID: 275167
• Weight: 25.3kg (55 lb, 12.4 oz)
• Weight Size: MD
