Specialized Stumpjumper Comp Alloy Mountain Bike (2023)

Price:   $1,960.00 $1,372.00

  • Model: 4704
  • 5 Units in Stock

Please Choose:

(complete orders today,deliverd around 27/04/2025)
  • Shipping time
    About 5-7 days.
  • means of transportation
    EMS,TNT,UPS,DHL,FEDX,HK AIR
  • Payment
    Credit Card
  • Email us
    [email protected]
  • New Products
    Pearl Izumi Women's Wander Bike Tights - Black
    $60.00
    Pearl Izumi Women's Wander Bike Tights
    $60.00
    Pearl Izumi Men's AMFIB Cycling Bib Tight - Black
    $123.00
    Giant Men's Transfer Mountain Bike Shorts
    $67.00
    • Details

    Metal fans rejoice! The Stumpjumper Comp Alloy rocks on, with one of the most advanced alloy frames ever developed. From the frame's asymmetrical design, taking in the refined suspension kinematics and all-new geometry, to a build kit that strikes the optimal combination of performance and value, it's metal, but it ain't heavy metal. And it's ready to slay some dirt.

    FEATURES

    THE TRAIL BENCHMARK - When we set out to design the all-new Stumpjumper, we pursued some hefty goals. It had to excel on any kind of trail, for every style of rider. To achieve that, we went after serious weight reduction without sacrificing durability, a stiff, responsive chassis that still rides light and lively, geometry that improves everyone's riding, and the best suspension kinematics we know how to design. Turns out, you can have your cake and eat it too with the new Stumpjumper.

    THE SWEETEST 130MM OF TRAVEL YOU'LL EVER RIDE - We massaged the kinematics of the Stumpjumper suspension to bring out the very best all-round performance possible in a 130mm package. Countless hours of suspension lab development and field testing created a refined mid-travel ripper that eats big terrain like a gravity fed beast, handles like a dream everywhere, and climbs like it has a motor.

    PROGRESSIVE GEOMETRY - The S-Sizing geometry of the new Stumpjumper hits the progressive sweet spot. It's long, low and slack, with a short offset fork and a steeper seat tube angle. These numbers combine to make your ride more stable, more carvealicious, more comfortable climbing, more better everywhere. With FlipChip adjustability you're able to further fine-tune your fit, ensuring that your new Stumpjumper performs flawlessly on whatever terrain you choose.

    RIDER-FIRST ENGINEERED - Rider-First Engineered frames use a size-specific approach to ride characteristics that ensures benchmark handling and flawless performance, regardless of frame or rider size. Whether you're a jump-happy grom riding an S1, or a DH-fiend giant in need of the lengthy S6, you'll experience the same ride traits - rail-sharp cornering and balanced front and rear stiffness - at the lightest-possible weight, And by light, we mean real light: 2,250 grams (S-Works, S-3 size, with rear shock).

    Specifications

    FrameAlloy chassis and rear-end, asymmetrical design, 29 Trail Geometry, horst pivot BB adjustment, threaded BB, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel
    Seat BinderAlloy, 38.6mm
    Rear ShockFOX FLOAT DPS Performance, Rx Trail Tune, rebound and 3-position compression adjust, S1:190x42.5mm, S2-S6: 190x45mm
    ForkFOX FLOAT 34 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm axle, 44mm offset, 140mm of travel
    StemAlloy Trail Stem, 35mm bar bore
    HandlebarsSpecialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
    TapeSpecialized Trail Grips
    SaddleBridge Comp, Hollow Cr-mo rails, 155/143mm
    SeatPostX-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 175mm, S6: 190mm
    Front BrakeSRAM G2 R, 4-piston caliper, hydraulic disc, 200mm
    Rear BrakeSRAM G2 R, 4-piston caliper, hydraulic disc, 180mm
    Rear DerailleurSRAM NX Eagle, 12-speed
    Shift LeversSRAM NX Eagle, trigger, 12-speed
    CassetteSRAM NX Eagle, 12-speed, 11-50t
    ChainSRAM NX Eagle, 12-speed
    CranksetSRAM NX Eagle, DUB, S1:165mm, S2-S5: 170mm, S6: 175mm
    ChainringsSteel, 30T
    Bottom BracketSRAM DUB, BSA 73mm, Threaded
    RimsSpecialized 29, hookless alloy, 30mm inner width, tubeless ready







    Front HubAlloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
    Rear HubAlloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
    SpokesDT Swiss Industry
    Front TireButcher, GRID casing, GRIPTON T9 compound, 2Bliss Ready, 29x2.3"
    Rear TirePurgatory, GRID casing, GRIPTON T7 compound, 29x2.3"
    Inner TubesStandard, Presta Valve

    Geometry

    S1S2S3S4S5S6
    Crank Length165mm170mm170mm170mm170mm175mm
    Handlebar Width780mm780mm780mm780mm780mm780mm
    Stem Length40mm40mm50mm50mm50mm50mm
    Saddle Width155mm155mm143mm143mm143mm143mm
    Seatpost Length100mm125mm150mm170mm170mm190mm
    Stack (Low BB)618mm613mm623mm631mm639mm649mm
    Stack (High BB)614mm609mm618mm627mm640mm644mm
    Reach (Low BB)410mm430mm450mm475mm500mm530mm
    Reach (High BB)416mm435mm455mm480mm505mm535mm
    Headtube Length100mm100mm110mm120mm130mm140mm
    Headtube Angle (Low BB)65°65°65°65°65°65°
    Headtube Angle (High BB)65.5°65.5°65.5°65.5°65.5°65.5°
    BB Height (Low BB)327mm332mm332mm332mm332mm332mm
    BB Height (High BB)334mm339mm339mm339mm339mm339mm
    BB Drop (Low BB)47mm42mm42mm42mm42mm42mm
    BB Drop (High BB)40mm35mm35mm35mm35mm35mm
    Trail (Low BB)126mm126mm126mm126mm126mm126mm
    Trail (High BB)122mm122mm122mm122mm122mm122mm
    Fork Length (full)550mm550mm550mm550mm550mm550mm
    Fork Rake/Offset44mm44mm44mm44mm44mm44mm
    Front Center726mm746mm770mm799mm828mm863mm
    Chainstay Length (Low BB)444mm444mm444mm444mm454mm454mm
    Chainstay Length (High BB)440mm440mm440mm440mm450mm450mm
    Wheelbase (Low BB)1168mm1188mm1212mm1241mm1280mm1315mm
    Wheelbase (High BB)1164mm1184mm1208mm1237mm1276mm1311mm
    Top-tube Length (horizontal)545mm563mm586mm615mm643mm676mm
    Bike Standover Height742mm742mm750mm753mm777mm784mm
    Seat Tube Length385mm385mm405mm425mm445mm465mm
    Seat Tube Angle (Low BB)77.7°77.7°77.5°77.2°77°76.9°
    Seat Tube Angle (High BB)78.2°78.2°77.9°77.7°77.5°77.3°
    Max Seatpost Insertion190mm190mm210mm230mm250mm270mm
    Min Seatpost Insertion100mm100mm100mm100mm100mm100mm
