Built for modern XC racing, this full-composite flyer tackles steep singletrack climbs and technical descents with speed and control. With FlexPoint Pro rear suspension and race-ready geometry, it puts you at the front of the pack. Ultra-efficientAdvanced composite frameset is 241g lighter than previous generation. The bottom bracket area is stiffer for faster acceleration, and a steeper seat tube puts the rider in an efficient climbing position.
Superior controlFlexPoint Pro suspension delivers 100mm of smooth, active rear travel. The frameset features modern XC geometry including a slacker 67.5-degree head tube and 110mm suspension fork for technical descents.
29er stability and speedFrame geometry and suspension are optimized for fast and stable 29-inch wheels. A longer reach and modified cockpit including a 35mm composite handlebar and alloy stem further boost balance and stability on XC terrain.
| | S | M | L | XL | | A | Seat Tube Length (MM) | 390 | 420 | 465 | 495 | | B | Seat Tube Angle | 75.5° | 75.5° | 75.5° | 75.5° | | C | Top Tube Length (MM) | 572 | 604 | 626 | 653 | | D | Head Tube Length (MM) | 90 | 95 | 105 | 115 | | E | Head Tube Angle | 67.5° | 67.5° | 67.5° | 67.5° | | F | Fork Rake (MM) | 44 | 44 | 44 | 44 | | G | Trail (MM) | 109.0 | 109.0 | 109.0 | 109.0 | | H | Wheelbase (MM) | 1127 | 1159 | 1183 | 1212 | | I | Chain Stay Length (MM) | 435 | 435 | 435 | 435 | | J | Bottom Bracket Drop (MM) | 42 | 42 | 42 | 42 | | K | Stack (MM) | 589 | 593 | 603 | 612 | | L | Reach (MM) | 420 | 450 | 470 | 495 | | M | Stand Over Height (MM) | 745 | 750 | 777 | 800 | | N | Handlebar Width (MM) | 760 | 760 | 760 | 760 | | O | Stem Length (MM) | 60 | 70 | 70 | 70 | | P | Crank Length (MM) | 170 | 175 | 175 | 175 | | Q | Wheel Size | 29" | 29" | 29" | 29" |
- Sizes: S, M, L, XL
- Colors: Raw Carbon/Brushed Chrome
- Frame: Advanced-grade composite front and rear triangles, 100mm FlexPoint Pro suspension, 12x148mm thru-axle
- Fork: Fox 34 Float SC Performance Elite remote, 110mm, GRIP SL damper, Boost 15x110 Kabolt, 44mm offset
- Shock: Fox Float SL Performance Elite, three-position remote, 165/45, custom tuned for Giant
- Handleba: rGiant Contact SLR XC Flat, composite, 760x35mm
- Stem: Giant Contact SL XC, 35mm S:60mm, M:70mm, L:70mm, XL:70mm
- Seatpost: Giant Contact Switch AT dropper, remote S: 110-140mm travel / 30.9 x 395mm M: 110-140mm travel / 30.9 x 395mm
- Saddle: Giant Grit SL
- Pedals: platform [GC,GT]
- Shifters: SRAM AXS Pod, discrete clamp, 1x12
- Front Derailleur: N/A
- Rear Derailleur: SRAM GX Eagle Transmission
- Brakes: Shimano Deore XT BR-M8100, hydraulic, Shimano RT-64 rotors [F]180mm, [R]160mm
- Brake Levers: Shimano Deore XT BL-M8100
- Cassette: SRAM GX Eagle Transmission, 10x52
- Chain: SRAM GX Eagle Transmission
- Crankset: SRAM XO Eagle Transmission with power meter, 32t, 55mm chainline S:170mm, M:175mm, L:175mm, XL:175mm
- Bottom Bracket: SRAM DUB, press fit
- Rims: Giant XCR 1 30 Carbon WheelSystem, 30mm inner width
- Hubs: [F] Giant XC alloy, CenterLock, [R] Giant XC alloy, DT350 54t ratchet driver, CenterLock
- Spokes: Sapim Laser
- Tires: Maxxis Aspen 29x2.4, foldable, 120tpi, TLR, EXO, tubeless
- Extras: tubeless prepared, 2.4" max tire size, 34t max chainring size, Giant/MRP CS chain guide
|
