Aventon Abound SR Ebike

Introducing the all-new Abound SR-the enhanced cargo ebike built to carry anything and tackle every challenge. Whether you're cruising through the streets or bike pooling with a friend, the Abound SR is always ready for any action. Its compact frame keeps you agile, while advanced securityand GPSfeatures give you total peace of mind.

Outfitted with an adjustable quill stem, suspension seat, and cutting-edge theft deterrent features, every ride is smooth, secure, and stress-free. Whether it's a quick trip or a big haul, the Abound SR is your go-to for dominating the road.

'

Enhanced security meets advanced technology

The revolutionary Aventon Control Unit (ACU) keeps you fully protected and always connected - all at the same time. Augmented security features including Remote Lock

Remote Lock & Geofence

The smart remote locking functionality lets you immobilize your bike right from the Aventon app. And the Geofencing feature lets you define the areas allowed and the distances prohibited. It's your ride and you're always in control.

E-Lock Kickstand & Alarm

Quickly, easily and securely lock your kickstand right from your display or the Aventon app. Also, whenever there is movement or tampering, the Abound SR's alarm

Passcode & Keyless Battery

Customize your passcode and maximize your protection. Choose from up to six inputs and with the all-new Keyless Battery, there's one less key on your ring, so you can just hop on and bop around.

New Side Display with Intuitive Controls

Inspired by the simplicity and function of iconic MP3 players, the controls on the sleek new side display gives you an easy access to everything you need. Rest assured, it now has a USB-C port to conveniently charge your phone while you ride.

Adjustable Quill Stem & BMX Style Handlebars

The Abound SR is where agility meets maneuverability. Set the height of your seat for ultimate comfort and adjust the handlebars for ultimate control.

Suspension Seat

No shocks. No vibrations. Just smooth riding. The sleek, padded suspension seat absorbs the impact of the road so all you feel is the exhilaration of the ride.

Ride Tune

Stay in perfect sync with your bike. Ride Tune lets you personalize your riding style via the Aventon App. Optimize and realize the full potential of your Abound SR.

Over the Air Updates

Stay in the know while on the go. Enjoy optimal performance with intelligent over-the-air software updates through the Aventon app. No need to plug in or stop at a shop. Ride on.

Rear Rack & Tunrsignal

With an array of accessories, the rear rack allows 143 lb weight capacity to carry your precious cargo while keeping them visible with integrated turn signals. Front & rear fenders with rear wheel mesh guards will keep you and your cargo safe from the elements.

• Model Abound SR Ebike
• Weight 80 lbs
• Total Weight Limit 440 lbs
• Rider Height 4'11" - 6'3"Class
• Class 2 EbikeWater ResistanceIPX4
• Ideal Use Cargo & Utility
• Pedal Assist 3 Levels
• Safety Certified UL Certified - Abound SR UL 2849, Battery UL 2271
• Range Up to 60 miles
• Folding No
• Fork Threaded Steerer Tube for Quill Stem 15x110 spacing, 50mm travel, adjustable lockout, black stanchions
• Frame Style Step-Through
• Frame 6061 Aluminum Alloy with Internal Battery. One piece - Diecast aluminum front triangle
• Wheelset Tires20 x 3.0 urban tire with reflective sidewalls
• Wheels 20-inch, 12-gauge, 36-hole, double-wall aluminum, black
• Ebike System
• Motor 36V 750w Hub Drive with 6 speed sensors
• Motor Torque 80Nm
• ECU Aventon ECU Module featuring wired CAN communication, GPS positioning support, wireless Bluetooth connectivity, and cellular communication capabilities
• Throttle Aventon LH Handlebar Mounted
• Sensors Double Sided
• Bottom Bracket Torque Sensor
• Charger Aventon 4A 42VDisplayAventon BC147SpeedClass 2
• Battery Aventon 36V, 20Ah, 708Wh, LG 21700 cells
• Rear Brake Rotor Tektro 203mm 6 bolt
• Front Brake Tektro HD-E3520 hydraulic disc brakes
• Rear Brake Tektro HD-E3520 hydraulic disc brakes
• Front Brake Rotor Tektro 180mm 6 bolt
• Chain 122 Link, 8 SpeedChainring52 tooth
• Crank3 piece with 165mm crank arms
• Rear Derailleur Shimano Altus RD-M310 8 Speed
• Shift Lever Shimano SL-M315-8R 8 Speed
• Cassette Shimano CS-HG200-8 8 speed Cassette, 12-32T
• Pedals 9/16" Composite Platform
• Saddle Aventon by SelleRoyal
• Seatpost 30.9mm Suspension Seatpost with 50mm travel
• Handlebars BMX Style, 31.8mm bar clamp, 680mm width
• Stem Quill Stem with 31.8mm bar clamp diameter, 40mm length, and 140mm of vertical adjustment
• Seat Clamp 34.9mm Quick Release
• Grips Lock-on ergonomic
• Included Accessories
• Rear Rack
• Included KickstandIncluded: E-lockRear Wheel Mesh GuardsIncluded
• Rear Rack Weight Limit 143 lbs

The Abound SR ships as a Class II ebike, with pedal assist and throttle going up to 20 MPH. The Abound SR will also operate with the throttle unplugged and removed, should you want to ride in an area where throttles are prohibited. Abound SR ebike and battery is UL Certified with UL 2849 for the ebike and UL 2271 for the battery. Aventon ebikes are built to the IPX4 water-resistant standard. IPX4 means that your bike is resistant to water splashes from any direction. This means it's OK to ride your ebike in light rain. It won't be harmed by spray from a wet road or raindrops. Your ebike is not intended to be exposed to prolonged rain, be submerged, or subjected to a pressurized spray. Don't use a pressure washer or sprayer to clean your ebike. *Max range is determined using PAS 1 throughout flat terrain with a rider weight of 160 lbs.
